Why Choose ABB Microlectric® Meter Sockets for Your Electrical Project?
The Microlectric® brand began in Montreal in 1970, and more than 50 years later, its meter bases are still designed and manufactured in Canada at ABB’s Iberville facility in Saint-Jean-sur-Richelieu, Quebec. Known for their durability and superior quality, Microlectric® meter sockets are built to withstand Canada’s harsh climate while meeting the latest electrical standards.
Whether you're an electrician, contractor, or utility provider, ABB’s Microlectric® solutions offer reliability, compliance, and long-term performance for your electrical projects.
Why Choose ABB Microlectric®?
Proudly Made in Canada
Microlectric® has been a Canadian brand since 1970, with all meter bases designed and manufactured at ABB’s Iberville facility in Saint-Jean-sur-Richelieu, Quebec. This ensures strict quality control and local support, making them a dependable choice for electricians and contractors.
Up to Code & BC Hydro Approved
Microlectric® products meet Canadian electrical code requirements and comply with BC Hydro’s instrument transformer enclosure standards. They are CSA-certified for overhead, underground, or combined service and are compatible with both copper and aluminum conductors to suit various installation needs.
Built to Handle Canada’s Harsh Climate
Designed for rugged environments, Microlectric® meter sockets feature weatherproof NEMA Type 3R enclosures that provide excellent outdoor durability. Their sturdy, high-quality construction allows them to withstand extreme temperatures, moisture, dust, and impact, ensuring a long service life in demanding conditions.
Versatile Solutions for Any Project
Microlectric® offers a complete range of meter bases, service entrance masts, pole line hardware, and accessories to meet diverse project needs. Whether you're installing a single-family residential meter socket or a multi-position meter base for commercial applications, ABB provides reliable and scalable solutions.
Microlectric® All-in-One 400
The ABB Microlectric® All-in-One 400 is equipped with field-installable conductors, dual-rated connectors, and weatherproof Type 3R enclosures for reliable, safe service in various installation conditions. It is designed for overhead and underground service, with options for easy wiring, a permanent red nameplate warning, and approval for revenue metering.
Key Features
- Load Side Terminations: Tunnel type connectors, dual-rated for 1 x 500 kcmil or 2 x 250 kcmil
- Dimensions: 30-5/8 in. H x 20-1/4 in. W x 8-3/8 in. D; made of heavy gauge galvanized steel with an oven-cured grey enamel finish. Weight: 72 lb. (32.7 kg)
- Knockouts: Three bottom knockouts for 1-1/4 in., 1-1/2 in., 2 in., 2-1/2 in., 3 in., 3-1/2 in., and 4 in. conduit
- Enclosure: Weatherproof Type 3R
- Metering: 400/5 A, 5 Jaw; provisions for test switches (test switches supplied by BC Hydro) and current transformer (transformer supplied by BC Hydro)
- Secondary Circuit Wiring: Not included (to be wired by BC Hydro)
Microlectric® CT-L Series
The ABB Microlectric® CT-L Series Meter Socket features aluminum tunnel-type connectors for both load and line sides, accommodating conductors ranging from 14–10 AWG. It also includes a circuit-closing feature to short out the current transformer upon meter removal.
- Transformer-Rated: 20 A, 600 V maximum
- Conductor Range: 14-10 AWG
- Connectors: Tunnel type connectors for both load and line sides
- Service Type: For underground service only
- Meter Compartment Cover: Overlaps the lower test switch compartment cover, with the meter securely holding the upper cover in place via a catch and an additional piece for extra security
- Protection: A cover conceals the hydro seal from view
- Test Switch Compartment: The lower test switch compartment cover is securely held by the upper cover and can be locked to restrict access
Get Expert Advice from EB Horsman & Son
Choosing the right meter socket for your project is essential for ensuring safety, compliance, and long-term reliability. At EB Horsman & Son, we offer a wide selection of ABB Microlectric® meter sockets and accessories to meet your specific needs. Our team of electrical experts is ready to provide product recommendations and technical support to help you complete your project with confidence.
